AAS 6013 AFB Dust Extraction Unit – Stationary Raw Air Dust Collector for Industrial Use
Enhance your dust extraction system with the AL-KO AAS 6013 AFB Dust Extraction Unit, a powerful and stationary solution for diverse materials such as plastic, metal, glass, styrofoam, paper, and wood for hobby purposes. The pre-assembled components, including filter bags, dust collection drums, support feet, and a mounted switch, make setup quick and easy.
Modular Overpressure Filter System
Sturdy Galvanized Steel Housing
High Dust Collection Capacity
Quick Installation
Reliable and Efficient Dust Collection Solution
The AAS 6013 AFB Dust Extraction Unit is designed for optimal dust and chip removal, promoting workplace safety and maintaining air quality. Its high-power motor and efficient design make it suitable for challenging industrial applications. This modular overpressure filter unit features a fan on the raw air side, optimized for high-performance dust collection.
Key Features
High-Powered Motor:
A 7.5 kW motor (400 V/50 Hz) with a maximum air volume of 7,300 m³/h and suction pressure of 2,900 Pa ensures powerful extraction performance.
Advanced Filtration System:
Six large filter units (totaling 13.2 m²) efficiently trap fine particles, maintaining a clean workspace.
Manual Filter Cleaning:
User-friendly hand-cleaning system simplifies maintenance and optimizes filter performance.
Spacious Dust Collection Capacity:
Six 175-liter drums reduce the need for frequent emptying, supporting efficient workflows.
Applications
Perfect for:
- Plastic and Metal Processing: Ensures safe and clean air quality by capturing fine dust and particulates.
- Glass and Styrofoam Processing: Reliable extraction of lightweight materials for a healthier environment.
- Workshops and Hobby Areas: Maintains dust control for various small-scale projects.
Technical Specifications
Intake Diameter:
300 mm
Motor Power:
7.5 kW (400 V/50 Hz)
Nominal Air Volume:
5,500 m³/h
Max Air Volume:
7,300 m³/h
Max Pressure:
2,900 Pa
Filter Area:
6 x 2.2 m²
Filter Cleaning:
Manual
Filter Category:
L
Dust Collection Capacity:
6 x 175 L
Dimensions (L x W x H):
4,786 x 787 x 2,754 mm
Weight:
319 kg with collection container
Finish:
RAL 7035 (Light Grey)
Discover the benefits of the AAS 6013 AFB Dust Extraction Unit, enhancing air quality and operational efficiency in industrial settings.
Note: Not approved for use in indoor workspaces in the woodworking industry in Germany, Austria, and Switzerland.
