Dust Extraction Unit AAS 1013 – Stationary Dust Collector for Versatile Applications
Enhance the air quality in your workspace with the Dust Extraction Unit AAS 1013. This stationary dust collector is universally designed for the extraction of dust and shavings from materials like plastic, metal, glass, Styrofoam, and paper. Constructed as a modular unit with an overpressure filter and a fan positioned on the raw air side, it is ideal for various industrial applications and hobby woodworking.
2.2 kW Motor
Efficient Filtration
Durable Design
Dependable and Efficient Dust Collection
The AAS 1013 Dust Extraction Unit delivers consistent performance and reliability for a variety of industrial and commercial uses. By effectively capturing dust and shavings, this unit contributes to a cleaner, safer working environment.
Key Features
Powerful Motor:
The 2.2 kW motor delivers strong suction capacity for demanding extraction tasks.
Advanced Filtration System:
The 2.2 m² filter area enables optimal airflow and particle removal.
Easy Assembly and Maintenance:
Preassembled parts and manual filter cleaning reduce maintenance time and improve efficiency.
Applications:
Perfectly suited for:
- Plastic Processing: Efficiently captures dust and particles generated in plastic production.
- Metal Processing: Ensures a clean work environment during metalworking.
- Glass and Styrofoam Processing: Effectively removes dust and debris from processing areas.
- Paper Processing: Maintains clean work surfaces in cutting and processing operations.
Technical Specifications:
Inlet Diameter:
Inlet Diameter:
Motor Power:
2.2 kW / 3 Ph
Voltage:
400 V/50 Hz
Nominal Flow Rate:
1,300 m³/h
Max. Flow Rate:
1,800 m³/h
Vacuum Pressure:
2,100 Pa
Filter Area:
2.2 m²
Filter Cleaning:
Manual
Dust Class:
L
Dust Collection Volume:
175 L
Dimensions (L x W x H):
1,149 × 578 × 2,115 mm
Weight:
61 kg
Color:
RAL 7035 (Light Grey)
Learn more about the benefits of the AAS 1013 Dust Extraction Unit and how it can create a safer and more efficient workspace. Check out our blog post to learn more about the Dust Extraction Units and more!
